MC cartridge ZG-MC201 The entry-level MC cartridge of Zhige is designed with an integrated body and movement, consisting of LCP, aluminum alloy, and brass components. The vocals of the cartridge are solid and visually appealing, and the instrument fusion is also good. It has a good sound field and surround feeling, and the sound is neither sharp nor hard, making it a great choice for entry-level players.

Type		MC Stereo	MC Stereo	MC MONO
Model		ZG-MC201	ZG-MC201H	ZG-MC201 MONO
Structure	Material of body	AL6063+LCP	AL6063+LCP	AL6063+LCP
	Stylus	Line Contact	Line Contact	Line Contact
	Cantilever	Aluminum	Aluminum	Aluminum
	Height (mm)	16.5	16.5	16.5
	Weight (g)	6.5	6.5	6.5
	Core Shape	cross	cross	cross
	Magnet	NdFeB	NdFeB	NdFeB
	Wire type	5NOCC	5NOCC	5N Silver
Electrical properties	Output level	0.4mV (1KHz, 5cm/s)	0.6mV (1KHz, 5cm/s)	0.4mV (1KHz, 5cm/s)
	DC Resistance	10Ω	20Ω	7Ω
	Frequency response	15-25KHz ±1dB	15-25KHz ±1dB	15-25KHz ±1dB
	Channel separation	>30dB	>30dB
	Channel balance	<0.5dB	<0.5dB	<0.5dB
Application parameters	Compliance(dynamic 10Hz)	16μm/Mn	16μm/mN	16μm/mN
	Recommended tracking force	1.8g	1.8g	1.8g
	Tracking force range	1.7-2.2g	1.7-2.2g	1.7-2.2g
	Run-in period	30h	30h	30h
