MC cartridge ZG-Ti105
MC cartridge ZG-Ti105
The entry-level MC cartridge Zhige is made of a composite of aluminum alloy and ebony wood, with low and high resistance types available. Characteristics of low impedance cartridge: The response to music and the speed of transient reactions are faster than ordinary impedance cartridge, and the presented contours are clearer. Characteristics of high impedance cartridge: increase coil internal resistance, remove front plate, reduce and modify the total magnetic circuit of the cartridge, thereby significantly reducing distortion and noise, and reproducing subtle sound details.
  • MC cartridge ZG-Ti105
  • MC cartridge ZG-Ti105
Type MC Stereo MC Stereo MC Stereo
Model ZG-Ti105 ZG-Ti105H ZG-Ti105S
Structure Material of body AL6063+Ebony AL6063+Ebony AL6063+ Sandalwood
Stylus Super Elliptic Super Elliptic Super Elliptic
Cantilever titanium alloy titanium alloy titanium alloy
Height  (mm) 17.8 17.8 17.8
Weight (g) 7.5 7.5 7.5
Core Shape cross cross cross
Magnet NdFeB NdFeB NdFeB
Wire type 5NOCC 5NOCC 5N Silver
Electrical properties Output level 0.3mV
(1KHz, 5cm/s)
0.5mV
(1KHz, 5cm/s)
0.35mV
(1KHz, 5cm/s)
DC Resistance 10Ω 20Ω 7Ω
Frequency response 15-25KHz  ±1dB 15-25KHz  ±1dB 15-30KHz  ±1dB
Channel separation >30dB >30dB >30dB
Channel balance <0.5dB <0.5dB <0.5dB
Application parameters Compliance(dynamic 10Hz) 15μm/mN 15μm/mN 15μm/mN
Recommended tracking force 1.8g 1.8g 1.8g
Tracking force range 1.7-2.2g 1.7-2.2g 1.7-2.2g
Run-in period 30h 30h 30h
