MC cartridge ZG-MC301 nightingale-Dongguan Beibei Voice Electronic Technology Co., Ltd

MC cartridge ZG-MC301 nightingale The body is made of ebony or small leaf rosewood, which is processed as a whole and better suppresses all mechanical resonances than metal. The cantilever structure adopts a long magnetic rod structure, which better suppresses subtle vibrations. The damping adopts an inner and outer ring structure, making the cartridge have a very smooth frequency response curve

Type		MC Stereo	MC Stereo	MC Stereo	MC Stereo	MC MONO
Model		ZG-MC301	ZG-MC301L	ZG-MC301H	ZG-MC301S	ZG-MC301 MONO
Nickname		nightingale 夜莺
Structure	Material of body	Ebony	Ebony	Ebony	Ebony	Ebony
	Stylus	Line Contact	Line Contact	Line Contact	Line Contact	Super Elliptic
	Cantilever	Boron	Boron	Boron	Boron	Aluminum
	Height (mm)	17.5	17.5	17.5	17.5	17.5
	Weight (g)	7	7	7	7	7
	Core Shape	cross	cross	cross	square	square
	Magnet	NdFeB	NdFeB	NdFeB	NdFeB	NdFeB
	Wire type	6NOCC	6NOCC	6NOCC	5N Silver	6NOCC
Electrical properties	Output level	0.3mV (1KHz, 5cm/s)	0.4mV (1KHz, 5cm/s)	0.6mV (1KHz, 5cm/s)	0.4mV (1KHz, 5cm/s)	0.5mV (1KHz, 5cm/s)
	DC Resistance	20Ω	10Ω	20Ω	7Ω	12Ω
	Frequency response	15-30KHz ±1dB	15-30KHz ±1dB	15-30KHz ±1dB	15-30KHz ±1dB	15-30KHz ±1dB
	Channel separation	>32dB	>32dB	>32dB	>32dB
	Channel balance	<0.5dB	<0.5dB	<0.5dB	<0.5dB	<0.5dB
Application parameters	Compliance(dynamic 10Hz)	15μm/mN	15μm/mN	15μm/mN	15μm/mN	15μm/mN
	Recommended tracking force	1.8g	1.8g	1.8g	1.8g	1.8g
	Tracking force range	1.7-2.2g	1.7-2.2g	1.7-2.2g	1.7-2.2g	1.7-2.2g
	Run-in period	30h	30h	30h	30h	30h
