MC cartridge ZG-K101
MC cartridge ZG-K101
The entry-level MC cartridge Zhige is made of a composite of aluminum alloy and ebony wood, with low and high resistance types available. Characteristics of low impedance cartridge: The response to music and the speed of transient reactions are faster than ordinary impedance cartridge, and the presented contours are clearer. Characteristics of high impedance cartridge: increase coil internal resistance, remove front plate, reduce and modify the total magnetic circuit of the cartridge, thereby significantly reducing distortion and noise, and reproducing subtle sound details.
  • MC cartridge ZG-K101
  • MC cartridge ZG-K101
Type MC Stereo MC Stereo
Model ZG-K101 ZG-K101H
Structure Material of body AL6063 AL6063
Stylus Elliptic Elliptic
Cantilever Aluminum Aluminum
Height  (mm) 17.5 17.5
Weight (g) 6.5 6.5
Core Shape cross cross
Magnet samarium-cobalt samarium-cobalt
Wire type 5NOCC 5NOCC
Electrical properties Output level 0.4mV
(1KHz, 5cm/s)
0.84mV
(1KHz, 5cm/s)
DC Resistance 6.5Ω 20Ω
Frequency response 15-20KHz  ±1dB 15-20KHz  ±1dB
Channel separation >28dB >28dB
Channel balance <0.5dB <0.5dB
Application parameters Compliance(dynamic 10Hz) 15μm/mN 15μm/mN
Recommended tracking force 1.8g 1.8g
Tracking force range 1.7-2.2g 1.7-2.2g
Run-in period 30h 30h
