MC cartridge ZG-K102-Dongguan Beibei Voice Electronic Technology Co., Ltd

MC cartridge ZG-K102 The entry-level MC cartridge Zhige is made of a composite of aluminum alloy and ebony wood, with low and high resistance types available. Characteristics of low impedance cartridge: The response to music and the speed of transient reactions are faster than ordinary impedance cartridge, and the presented contours are clearer. Characteristics of high impedance cartridge: increase coil internal resistance, remove front plate, reduce and modify the total magnetic circuit of the cartridge, thereby significantly reducing distortion and noise, and reproducing subtle sound details.

Type		MC Stereo	MC Stereo
Model		ZG-K102	ZG-K102H
Structure	Material of body	Ebony	Ebony
	Stylus	Elliptic	Elliptic
	Cantilever	Aluminum	Aluminum
	Height (mm)	18.2	18.2
	Weight (g)	6.5	6.5
	Core Shape	cross	cross
	Magnet	samarium-cobalt	samarium-cobalt
	Wire type	5NOCC	5NOCC
Electrical properties	Output level	0.4mV (1KHz, 5cm/s)	0.8mV (1KHz, 5cm/s)
	DC Resistance	6.5Ω	20Ω
	Frequency response	20-25KHz ±1dB	20-25KHz ±1dB
	Channel separation	>28dB	>28dB
	Channel balance	<0.5dB	<0.5dB
Application parameters	Compliance(dynamic 10Hz)	15μm/mN	15μm/mN
	Recommended tracking force	1.8g	1.8g
	Tracking force range	1.7-2.2g	1.7-2.2g
	Run-in period	30h	30h
