MM cartridge
| Material of body | Aluminum |
| Stylus | Elliptical diamond tip |
| Cantilever | Aluminum |
| Color | Red |
| Height (mm) | 17.5 |
| Weight (g) | 8.2 |
| Output level | 3.6mV(1KHz,5cm/s) |
| DC Resistance | 480Ω |
| Load resistor | 47KΩ |
| Load Capacitance | 100pF |
| Frequency response | 20-20KHz ±1dB |
| Channel separation | >23dB |
| Channel balance | <1dB |
| Recommended tracking force | 1.8g |
| Tracking force range | 1.7-2.5g |
| Compliance(dynamic 10Hz) | 15um/mN |
| Run-in period | 30h |
| Configuration, packaging box, screws, washers | |
